BenQ TZY31 corporate InstaShare Button Solution

All Specifications

InstaShare Button

Color: Silver
Wireless Transmission Frame Rate:Up to 60 fps depending on environment (1080P60/4K30P)
TX Button Input resolution: Up to 4K30P
Audio Rate: Stereo, Radio quality 16bits 48KHz
Wi-Fi Standard: IEEE 802.11ac 5GHz, 2T2R MIMO
Authentication protocol: Wi-Fi Standard
Wireless Security (Encryption): WPA2/3 Personal/WPA2 Enterprise Support AES-256
Wireless Coverage Reach: Max. 15 m (Between Button and IFP)
Cable: USB Type C
Power Supply: DC 5V±10%, Minimum 0.9A
Power Consumption: Max 4.5W Full Loading
Dimension (WxHxD): 67mm x 67mm x23.2mm
Temperature range:
Operating: 0°C to +40°C (+32°F to +104°F)
Storage: -10°C to +60°C (+14°F to +140°F)
Humidity range:
Operating: 10% to 80% relative humidity
Storage: 5% to 90% relative humidity (non-condensing)
Compatibility:
1. RM03 series (with USB Type-C)
2. RP02, RE01, RM02K, RM02S, CP01K, CS01, SL02K series, and VC01A (with USB Type-C to USB Type-A adapter)

BenQ Wireless USB Dongle

Color: Black
Wi-Fi Standard: 802.11 a/b/g/n/ac
Interface: USB 3.0
Wi-Fi band: Dual Band 2.4GHz / 5GHz
MU-MIMO: Yes
Wi-Fi Performance:
2.4 GHz Band: up to 400 Mbps

5 GHz Band: up to 867 Mbps
External Antenna: 2
Supported OS: Android
Wireless Coverage Reach: Max. 15 m (Between Dongle and IFP)
Security: WPA-PSK/WPA2-PSK WPA/WPA2/WEP
Power Supply: DC 5V, 0.9A (Maximum)
Dimension L*H*W: 137 x 41 x 12 mm
Net Weight: 0.055kg
Temperature range:
Operation : 0℃~40℃
Storage : -40℃~70℃
Humidity range
Operation: 10%~90%
Storage: 5%~90%

Compatibility:

RM6503, RM7503, RM8603
RP6502, RP7502, RP8602
RE6501, RE7501, RE8601, RE9801
RM6502K, RM7502K, RM8602K
RM6502S, RM7502S, RM8602S
CP6501K, CP8601K
CS6501, CS7501, CS8601
SL5502K, SL6502K, SL7502K, SL8502K
ST4302, ST5502, ST6502, ST7502, ST8602
IL4301, IL5501
BH2401, BH2401T, BH2801, BH2801N, BH3501, BH3501T, BH3801, BH3801D, BH3801N
VC01A

BenQ InstaShare Dock

Color: Black
Weight (Net): 420g
Dimension L*H*W: 150 x 85 x 106 mm
InstaShare Button Loading quantity: 4 pcs
Product material: PC+ABS & Aluminum alloy 6063 & Silica gel
