Bluetooth® Communication (Receiver)
AAC
Yes
SBC
Yes
LDAC
Yes
Color
Color
Black
Firmware Update
via Network
Yes
Function for Custom Installation
Control Features
CIS IP Control: Yes
Controller Connectivity
Certification (Crestron/Control4/Savant): Yes, Certification (IHIJI): Yes
Function with BRAVIA
ACOUSTIC CENTER SYNC
Yes
VOICE ZOOM
Yes
Quick Setting Menu
Yes
Interfaces
Display
LED indicator: Yes, LED Indicator OFF Mode: Yes
Button on main unit
Power: Yes
HDMI
Number of Input/Output: 1 / 1 (eARC/ARC), eARC: Yes, 3D pass through: Yes, 4K/60p/YUV4:4:4: Yes, 8K/60 YUV 4-2-0 10bit (Non compression): Yes, 4K/120 YUV4-4-4 10bit (Non compression): Yes, HDR: Yes, Dolby Vision: Yes, HLG (hybrid log gamma): Yes
Wi-Fi
Wi-fi method: Yes, IEEE802.11 version: a/b/g/n/ac
Speaker Terminal
S-Center out: Yes
Network Service
Spotify Connect
Yes
AirPlay 2
Yes
Power
Power Consumption
Power Consumption(On Operation) *approx: 60W, Power Consumption(On Standby mode) *approx: Less than 0.5W, Power consumption(Bluetooth® standby mode) *approx¹³: Less than 2.3W Power consumption(Network standby mode) *approx: Less than 2.3W
Power Supply
Power Requirement: 120 V, Power frequency: 60 Hz
Power Cable Length
Bar Speaker (mm): 1600
Plug details
AC plug type: A
Power Setting
Auto Standby: Yes, Network / Bluetooth® Standby Mode¹³: Yes
Shop Front Mode
Built in Demo
Yes
USB playback demo
Yes
DEMO mode(1/2/3/4)
Yes (Yes/Yes/-/-)
Sound Function
Sound Mode
Sound Field: Yes
Sound Effect
Night Mode: Yes, Voice Mode: Yes
Sound Adjustment
Subwoofer volume: Yes(w Option Woofer), Bass level: Yes, AV Sync: Yes, Rear Speaker volume: Yes(w Option Rear), Advanced Auto Volume(AAV): Yes, Audio DRC: Yes, Mute: Yes, Rear level: Yes
Sound Enhancement
DSEE Ultimate: Yes
Surround
Dolby Speaker Virtual: Yes, Dolby Surround: Yes, Neural:X: Yes
DCAC Feature
Sound Field Optimization: Yes, mic for DCAC: Yes(built-in)
Speaker Layout
Speaker Structure
11 units
Speaker Unit(Side)
Full Range
Number of speaker: 2, Enclosure Type: Acoustic suspension, Unit size (mm): 46 x 54, Unit size (inch): 1 13/16 x 2 1/4, Driver Unit: cone, X-Balanced Speaker Unit: Yes
Operation
Easy Setup
Yes(BCA)
Speaker Unit(front)
Woofer
Number of speaker: 2, Enclosure Type: Acoustic suspension, Unit size (mm): 45 x 90, Unit size (inch): 1 13/16 x 3 5/8, Driver Unit: cone, X-Balanced Speaker Unit: Yes
Tweeter
Number of speaker: 2, Unit size (mm): 10, Unit size (inch): 13/32, Driver Unit: soft dome
Upfiring Speaker
Upfiring Speaker: 2, Unit size (mm): 46 x 54, Unit size (inch): 1 13/16 x 2 1/4, Driver Unit: cone, X-Balanced Speaker Unit: Yes
Speaker Grill
Speaker Grill (Bar)
Bar grill type: fixed, Front Grille Material: Fabric
Speaker Unit(Center)
Woofer
Number of speaker: 2, Enclosure Type: Acoustic suspension, Unit size (mm): 45 x 90, Unit size (inch): 1 13/16 x 3 5/8, Driver Unit: cone, X-Balanced Speaker Unit: Yes
Tweeter
Number of speaker: 1, Unit size (mm): 22, Unit size (inch): 7/8, Driver Unit: soft dome
Wireless Function
Wireles Surround (with optional wireless speakers)
Yes
Amplifier
Amplifier Type
Digital Amplifier: Yes, S-Master HX: Yes
Number of Channel
11ch
Output Power
Front Woofer(Reference): 45W+45W, Front Tweeter(Reference): 45W+45W, Center Woofer(Reference): 45W+45W, Center Tweeter(Reference): 45W, Side Speaker(Reference): 45W+45W, Enabled Speaker(Reference): 45W+45W
Bluetooth® Specification
Bluetooth® Communication(RX / TX) ¹³
RX/-
A2DP
Yes
AVRCP
Yes
Bluetooth® version ¹³
5.2
Bluetooth® Standby ¹³
Yes
Application
Sony | BRAVIA Connect
Sony | Home Entertainment Connect via Wi-Fi: Yes
Weight and Measurements
Dimensions (Approx.)
bar speaker (WxHxD) mm: 1100 x 64 x 113, bar speaker (WxHxD) inch: 43 3/8 x 2 5/8 x 4 1/2, carton type: Box, Carton (WxHxD) mm: W1204 x H137 x D250
Weight (Approx.)
bar speaker (kg): 4.7, bar speaker (oz): 10 lb 6 oz
Decode Format
High Resolution Audio
Yes
360 Reality Audio
Yes
HDMI input
DTS 96/24: Yes, DTS:X: Yes, IMAX ENHANCED: future update, LPCM: 2ch/5.1ch/7.1ch, LPCM fs: -192kHz/24bit, MPEG-H 3D Audio BL profile(Level3/Level4): Yes, 360 Reality Audio: Yes
HDMI ARC
Dolby Digital: Yes, Dolby Digital Plus: Yes, Dolby Digital Plus/Atmos: Yes, Dolby Dual mono: Yes, DTS: Yes, DTS 96/24: Yes, LPCM 2ch: Yes, LPCM fs: 48kHz/24bit
HDMI eARC
DTS ES: Yes, DTS 96/24: Yes, DTS:X: Yes, IMAX ENHANCED: future update, LPCM: 192kHz/24bit
Supplied Accessories
Remote Commander
Model Name: RHT-AH513U, Batteries for remote commander: Yes
Cable
TV center speaker mode cable, HDMI Cable, AC Cord
Instruction Manual / Reference Guide
English(US) or English(GB): Yes, French or French(CA): Yes, Spanish or Spanish(LA): Yes
Card
Warranty Card
Others
Wall mounting bracket: Yes, Wall mounting template: Yes, Foot: Yes
Interface
HDMI
HDCP2.2: Yes, HDCP2.3: Yes, 18Gbps: Yes, 40Gbps: Yes, x.v.Color (xvYCC): Yes, HDMI control: Yes, Scene Select Sync: Yes, Home Theater Control: Yes, BRAVIA Sync: Yes, HDMI CEC: Yes, HDMI standby through: Yes
